DX2R005HN2E700 is Obsolete and no longer manufactured.
Available Substitutes:
Direct
Direct
Parametric Equivalent
Parametric Equivalent
Parametric Equivalent
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
DX2R005HN2E700 | ||
|---|---|---|
Digi-Key Part Number | 670-1190-2-ND - Tape & Reel (TR) 670-1190-1-ND - Cut Tape (CT) 670-1190-6-ND - Digi-Reel® | |
Manufacturer | ||
Manufacturer Product Number | DX2R005HN2E700 | |
Description | CONN RCPT USB2.0 MINI B SMD R/A | |
Detailed Description | USB - mini B USB 2.0 Receptacle Connector 5 Position Surface Mount, Right Angle | |
Customer Reference | ||
Datasheet | Datasheet | |
EDA/CAD Models | DX2R005HN2E700 Models | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | JAE Electronics | |
Series | ||
Package | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Product Status | Obsolete | |
Connector Type | USB - mini B | |
Number of Contacts | 5 | |
Gender | Receptacle | |
Specifications | USB 2.0 | |
Mounting Type | Surface Mount, Right Angle | |
Mounting Feature | Horizontal | |
Termination | Solder | |
Features | Board Guide, Solder Retention | |
Ingress Protection | - | |
Operating Temperature | -20°C ~ 60°C | |
Number of Ports | 1 | |
Current Rating (Amps) | 1A | |
Voltage - Rated | 30V | |
Mating Cycles | 5000 | |
Shielding | Unshielded | |
Contact Finish | Gold | |
Shell/Shielding Material | Copper Alloy | |
Material Flammability Rating | - | |
Insulation Color | Black |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | |
| PCN Obsolescence/ EOL | Multiple Devices 17/Apr/2015 |
| HTML Datasheet | Input-Output Selection Guide |
| EDA Models | DX2R005HN2E700 Models |
| Product Drawings | DX2R005HN2E700 |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| ECCN | EAR99 |
| HTSUS | 8536.69.4040 |
Obsolete
,-Concave_tmb.jpg "0ZCF0050FF2C")
Substitutes (6)
| Part No. | Manufacturer | Quantity Available | Digi-Key Part No. | Unit Price | Substitute Type |
|---|---|---|---|---|---|
| 1-1734035-2 | TE Connectivity AMP Connectors | 1,787 | A123086CT-ND | £1.46000 | Direct |
| 690-005-299-043 | EDAC Inc. | 74,620 | 151-1206-1-ND | £0.51000 | Direct |
| 934TR | Keystone Electronics | 0 | 36-934TR-ND | £0.61110 | Parametric Equivalent |
| MUSB-05-F-B-SM-A-R-TR | Samtec Inc. | 0 | 612-MUSB-05-F-B-SM-A-R-TR-ND | £0.78125 | Parametric Equivalent |
| MUSB-05-F-B-SM-A-TR | Samtec Inc. | 3,108 | SAM14223CT-ND | £1.07000 | Parametric Equivalent |
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | 670-1190-6 670-1190-1 670-1190-2 |
| Standard Package | 700 |
