ESD Protection Diodes
In Ultra-Compact Chip Level Package (CLP)
Vishay's single-line ESD protection Diodes and 4-line ESD Protection array in the ultra-compact Chip Level Package, offering an extreme size reduction over previous-generation components with optimized performance such as low capacitance and leakage current for the protection of high-speed data lines against transient voltage signals.
ESD Protection Diodes
| Image | Manufacturer Part Number | Description | Type | Unidirectional Channels | Voltage - Reverse Standoff (Typ) | Available Quantity | Price | View Details | |
|---|---|---|---|---|---|---|---|---|---|
 |  | VBUS052BD-HTF-GS08 | TVS DIODE 5VWM 16VC 4-LLP75 | Zener | 2 | 5V (Max) | 0 - Immediate | See Page for Pricing | View Details |
|  | VBUS54CV-HSF-G4-08 | TVS DIODE 5.5VWM 22VC LLP75-6L | Steering (Rail to Rail) | 4 | 5.5V (Max) | 15284 - Immediate | $0.55 | View Details |
|  | VBUS053AZ-HAF-GS08 | TVS DIODE 5.5VWM 18VC LLP75-7L | Steering (Rail to Rail) | 3 | 5.5V (Max) | 16585 - Immediate | $0.28 | View Details |
| | VBUS053CZ-HAF-G-08 | TVS DIODE 5.5VWM 18VC LLP75-7L | Steering (Rail to Rail) | 3 | 5.5V (Max) | 14134 - Immediate | $0.51 | View Details |
|  | VBUS54FD-SD1-G4-08 | TVS DIODE 5.5VWM 15VC CLP1007-FL | Zener | 4 | 5.5V (Max) | 0 - Immediate | $0.34 | View Details |
|  | VBUS05B1-SD0-G4-08 | TVS DIODE 5.5VWM 18VC CLP0603 | Zener | 1 | 5.5V (Max) | 134655 - Immediate | $0.08 | View Details |
|  | VCUT07B1-HD1-G4-08 | TVS DIODE 7VWM 15VC LLP1006-2L | Zener | 1 | 7V (Max) | 49162 - Immediate | $0.14 | View Details |
