LVRC SERIES
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
LVRC SERIES
LVR Series Drawing

LVR05R0500FE73

Digi-Key Part Number
LVRC-.05RTR-ND - Tape & Reel (TR)
LVRC-.05RCT-ND - Cut Tape (CT)
Manufacturer
Manufacturer Product Number
LVR05R0500FE73
Description
RES 0.05 OHM 1% 5W AXIAL WW
Detailed Description
50 mOhms ±1% 5W Through Hole Resistor Axial Current Sense, Moisture Resistant Wirewound
Customer Reference
Datasheet Datasheet
Product Attributes
Type
Description
Select
Category
Mfr
Vishay Dale
Series
Package
Tape & Reel (TR)
Cut Tape (CT)
Product Status
Obsolete
Resistance
50 mOhms
Tolerance
±1%
Power (Watts)
5W
Composition
Wirewound
Features
Current Sense, Moisture Resistant
Temperature Coefficient
±100ppm/°C
Operating Temperature
-65°C ~ 275°C
Package / Case
Axial
Supplier Device Package
Axial
Size / Dimension
0.330" Dia x 0.925" L (8.38mm x 23.50mm)
Height - Seated (Max)
-
Number of Terminations
2
Failure Rate
-
Environmental & Export Classifications
AttributeDescription
RoHS StatusROHS3 Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
ECCNEAR99
HTSUS8533.21.0080
Alternate Packaging
Additional Resources
AttributeDescription
Other Names
LVRC-.05RCT
LVRC-.05RTR
Standard Package500
